This smart switch is designed to control 3 lights. The switch has a current sensor – which protects the switch from overload. It also measures the current consumption of the switch.
Technical Information
Power supply
100-240V | 50-60 Hz
Load range
0-5A
Transmission frequency
433.5-434.5 Mhz
Transmission range
up to 100M
Functionality
On/off, two way switch, scenario switch, timed switch, Double scenario switch
Background lighting
Shade of color and brightness can be set in the application
Current sensor
0-30A
Protections and safety
Triple protection: 1// Thermal fuse for protection against overheating. 2// Current sensor protection. 3// 5A fuse protection
This will disable the physical switch, however the switch will still operate from the application. It is also possible to create a scenario that can lock a group of switches. You are also able to create a timer that will operate the lock scenario.
Change the length of time needed to touch the switch until it operates. Useful when you want to prevent accidental touches from triggering the switch. For example, a delayed press on a scenario to turn off multiple switches.
